Description
TECHNICAL DATA
| Machinable products | Beads |
| Max. Diameter Beads | 12 mm |
| Number of working axes | 5 |
| Axis tilt Table | -65° / +65° |
| Axis tilt Tool Heads | -135° / +135° |
| Beads loader | |
| Max. number of beads | 15 beads/min |
| Vertical Head | |
| Tool rotation speed | from 0 to 20000 rpm |
| Tool pincer diameter | 6 mm |
| Horizontal Head | |
| Tool rotation speed | from 0 to 15000 rpm |
| Tool diameter | 80 mm |
| Installation data | |
| Wattage | 3 kW |
| Power supply | 230 V, 50/60 Hz, 1~ |
| Pneumatic supply | 6 bar |
| Max. air consumption | 60 Nl/min |
| Weight | 500 kg |
